Definition Type: ComplexType
Name: OperationReferenceBaseType
Namespace: http://www.openapplications.org/oagis/9
Type: oa:DocumentReferenceBaseType
Containing Schema: Components.xsd
Abstract
Collapse XSD Schema Diagram:
Drilldown into StepType in schema fields_xsd1 Drilldown into StepID in schema fields_xsd1 Drilldown into SequenceCode in schema fields_xsd1 Drilldown into GroupName in schema fields_xsd1 Drilldown into Status in schema components_xsd1 Drilldown into StatusCode in schema fields_xsd1 Drilldown into Note in schema fields_xsd1 Drilldown into Description in schema fields_xsd1 Drilldown into FreeFormTextGroup in schema meta_xsd Drilldown into DocumentDateTime in schema fields_xsd1 Drilldown into AlternateDocumentID in schema components_xsd1 Drilldown into DocumentID in schema components_xsd1 Drilldown into DocumentIDsGroup in schema components_xsd1 Drilldown into DocumentReferenceBaseType in schema components_xsd1XSD Diagram of OperationReferenceBaseType in schema components_xsd1 (HR-XML - Human Resources XML)
Collapse XSD Schema Code:
<xsd:complexType name="OperationReferenceBaseType">
    <xsd:complexContent>
        <xsd:extension base="DocumentReferenceBaseType">
            <xsd:sequence>
                <xsd:element ref="GroupName" minOccurs="0" maxOccurs="unbounded" />
                <xsd:element ref="SequenceCode" minOccurs="0" />
                <xsd:element ref="StepID" minOccurs="0" />
                <xsd:element ref="StepType" minOccurs="0" />
            </xsd:sequence>
        </xsd:extension>
    </xsd:complexContent>
</xsd:complexType>
Collapse Child Elements:
Name Type Min Occurs Max Occurs
DocumentID oa:DocumentID 0 (1)
AlternateDocumentID oa:AlternateDocumentID 0 unbounded
DocumentDateTime oa:DocumentDateTime 0 (1)
Description oa:Description 0 unbounded
Note oa:Note 0 unbounded
StatusCode oa:StatusCode 0 (1)
Status oa:Status 0 unbounded
GroupName oa:GroupName 0 unbounded
SequenceCode oa:SequenceCode 0 (1)
StepID oa:StepID 0 (1)
StepType oa:StepType 0 (1)
<xs:group> oa:DocumentIDsGroup 0 (1)
<xs:group> oa:FreeFormTextGroup 0 (1)
Collapse Derivation Tree:
Collapse References:
oa:OperationReferenceType
