Definition Type: ComplexType
Name: BODType
Namespace: http://www.starstandard.org/STAR/5
Containing Schema: BOD.xsd
Abstract
Documentation:
The outcome of processing a specific BOD. Describes overall/summary outcome, plus the outcome of processing each noun of the BOD. Includes noun-specific error and/or warning messaages encountered during processing. May include summary and/or roll-up messages at the BOD level.
Collapse XSD Schema Diagram:
Drilldown into PartialBODFailureMessage in schema meta_xsd1 Drilldown into BODSuccessMessage in schema meta_xsd1 Drilldown into BODFailureMessage in schema meta_xsd1 Drilldown into Note in schema fields_xsd1 Drilldown into Description in schema fields_xsd1 Drilldown into FreeFormTextGroup in schema meta_xsd1XSD Diagram of BODType in schema bod_xsd1 (Standards for Technology in Automotive Retail)
Collapse XSD Schema Code:
<xsd:complexType name="BODType">
    <xsd:annotation>
        <xsd:documentation> The outcome of processing a specific BOD. Describes overall/summary outcome, plus the
            outcome of processing each noun of the BOD. Includes noun-specific error and/or warning messaages
            encountered during processing. May include summary and/or roll-up messages at the BOD level.
         </xsd:documentation>
    </xsd:annotation>
    <xsd:sequence>
        <xsd:annotation>
            <xsd:documentation> OriginalApplicationArea is depricated from the BOD of the ConfirmBOD, the
               OriginalApplicationArea should be used off of the Confirm Verb.</xsd:documentation>
        </xsd:annotation>
        <!--
            <xsd:element ref="OriginalApplicationArea" minOccurs="0"> <xsd:annotation> <xsd:documentation
            source="http://www.openapplications.org/oagis/9"> A copy of the ApplicationArea for the original BOD that
            was processed. Present either as additional reference information, or for use in identifying the BOD in
            situations where a BODReference is not known. </xsd:documentation> </xsd:annotation> </xsd:element>
         -->
        <xsd:group ref="oagis:FreeFormTextGroup" />
        <xsd:element ref="oagis:BODFailureMessage" minOccurs="0" />
        <xsd:element ref="oagis:BODSuccessMessage" minOccurs="0" />
        <xsd:element ref="oagis:PartialBODFailureMessage" minOccurs="0" />
        <!-- <xsd:element ref="UserArea" minOccurs="0" /> -->
    </xsd:sequence>
</xsd:complexType>
Collapse Child Elements:
Name Type Min Occurs Max Occurs
Description oagis:Description 0 unbounded
Note oagis:Note 0 unbounded
BODFailureMessage oagis:BODFailureMessage 0 (1)
BODSuccessMessage oagis:BODSuccessMessage 0 (1)
PartialBODFailureMessage oagis:PartialBODFailureMessage 0 (1)
<xs:group> oagis:FreeFormTextGroup (1) (1)
Collapse Derivation Tree:
Collapse References:
star:BOD
