Documentation for Financial Information eXchange (FIX)
Definition Type: AttributeGroup
Name: ConfirmationAttributes
Namespace: http://www.fixprotocol.org/FIXML-4-4
Containing Schema: fixml-confirmation-base-4-4.xsd
Collapse XSD Schema Diagram:
Drilldown into SharedComm in schema fixml-confirmation-base-4-4_xsd Drilldown into SettlDt in schema fixml-confirmation-base-4-4_xsd Drilldown into SettlTyp in schema fixml-confirmation-base-4-4_xsd Drilldown into SettlCurrFxRtCalc in schema fixml-confirmation-base-4-4_xsd Drilldown into SettlCurrFxRt in schema fixml-confirmation-base-4-4_xsd Drilldown into SettlCcy in schema fixml-confirmation-base-4-4_xsd Drilldown into SettlCurrAmt in schema fixml-confirmation-base-4-4_xsd Drilldown into MatNetMny in schema fixml-confirmation-base-4-4_xsd Drilldown into NetMny in schema fixml-confirmation-base-4-4_xsd Drilldown into TotTakedown in schema fixml-confirmation-base-4-4_xsd Drilldown into Concession in schema fixml-confirmation-base-4-4_xsd Drilldown into EndCsh in schema fixml-confirmation-base-4-4_xsd Drilldown into StartCsh in schema fixml-confirmation-base-4-4_xsd Drilldown into EndAcrdIntAmt in schema fixml-confirmation-base-4-4_xsd Drilldown into IntAtMat in schema fixml-confirmation-base-4-4_xsd Drilldown into AcrdIntAmt in schema fixml-confirmation-base-4-4_xsd Drilldown into AcrdIntRt in schema fixml-confirmation-base-4-4_xsd Drilldown into ExDt in schema fixml-confirmation-base-4-4_xsd Drilldown into NumDaysInt in schema fixml-confirmation-base-4-4_xsd Drilldown into GrossTrdAmt in schema fixml-confirmation-base-4-4_xsd Drilldown into ProcCode in schema fixml-confirmation-base-4-4_xsd Drilldown into EncTxt in schema fixml-confirmation-base-4-4_xsd Drilldown into EncTxtLen in schema fixml-confirmation-base-4-4_xsd Drilldown into Txt in schema fixml-confirmation-base-4-4_xsd Drilldown into RptedPx in schema fixml-confirmation-base-4-4_xsd Drilldown into AvgParPx in schema fixml-confirmation-base-4-4_xsd Drilldown into PxTyp in schema fixml-confirmation-base-4-4_xsd Drilldown into AvgPxPrcsn in schema fixml-confirmation-base-4-4_xsd Drilldown into AvgPx in schema fixml-confirmation-base-4-4_xsd Drilldown into AcctTyp in schema fixml-confirmation-base-4-4_xsd Drilldown into ActIDSrc in schema fixml-confirmation-base-4-4_xsd Drilldown into Acct in schema fixml-confirmation-base-4-4_xsd Drilldown into LastMkt in schema fixml-confirmation-base-4-4_xsd Drilldown into Ccy in schema fixml-confirmation-base-4-4_xsd Drilldown into Side in schema fixml-confirmation-base-4-4_xsd Drilldown into QtyTyp in schema fixml-confirmation-base-4-4_xsd Drilldown into Qty in schema fixml-confirmation-base-4-4_xsd Drilldown into TrdDt in schema fixml-confirmation-base-4-4_xsd Drilldown into TxnTm in schema fixml-confirmation-base-4-4_xsd Drilldown into IndAllocID in schema fixml-confirmation-base-4-4_xsd Drilldown into AllocID2 in schema fixml-confirmation-base-4-4_xsd Drilldown into AllocID in schema fixml-confirmation-base-4-4_xsd Drilldown into CnfmStat in schema fixml-confirmation-base-4-4_xsd Drilldown into LegalCnfm in schema fixml-confirmation-base-4-4_xsd Drilldown into CopyMsgInd in schema fixml-confirmation-base-4-4_xsd Drilldown into CnfmTyp in schema fixml-confirmation-base-4-4_xsd Drilldown into CnfmTransTyp in schema fixml-confirmation-base-4-4_xsd Drilldown into CnfmReqID in schema fixml-confirmation-base-4-4_xsd Drilldown into CnfmRefID in schema fixml-confirmation-base-4-4_xsd Drilldown into CnfmID in schema fixml-confirmation-base-4-4_xsdXSD Diagram of ConfirmationAttributes in schema fixml-confirmation-base-4-4_xsd (Financial Information eXchange (FIX))
Collapse XSD Schema Code:
<xs:attributeGroup name="ConfirmationAttributes">
    <xs:attribute name="CnfmID" type="ConfirmID_t" use="required" />
    <xs:attribute name="CnfmRefID" type="ConfirmRefID_t" use="optional" />
    <xs:attribute name="CnfmReqID" type="ConfirmReqID_t" use="optional" />
    <xs:attribute name="CnfmTransTyp" type="ConfirmTransType_t" use="required" />
    <xs:attribute name="CnfmTyp" type="ConfirmType_t" use="required" />
    <xs:attribute name="CopyMsgInd" type="CopyMsgIndicator_t" use="optional" />
    <xs:attribute name="LegalCnfm" type="LegalConfirm_t" use="optional" />
    <xs:attribute name="CnfmStat" type="ConfirmStatus_t" use="required" />
    <xs:attribute name="AllocID" type="AllocID_t" use="optional" />
    <xs:attribute name="AllocID2" type="SecondaryAllocID_t" use="optional" />
    <xs:attribute name="IndAllocID" type="IndividualAllocID_t" use="optional" />
    <xs:attribute name="TxnTm" type="TransactTime_t" use="required" />
    <xs:attribute name="TrdDt" type="TradeDate_t" use="required" />
    <xs:attribute name="Qty" type="AllocQty_t" use="required" />
    <xs:attribute name="QtyTyp" type="QtyType_t" use="optional" />
    <xs:attribute name="Side" type="Side_t" use="required" />
    <xs:attribute name="Ccy" type="Currency_t" use="optional" />
    <xs:attribute name="LastMkt" type="LastMkt_t" use="optional" />
    <xs:attribute name="Acct" type="AllocAccount_t" use="required" />
    <xs:attribute name="ActIDSrc" type="AllocAcctIDSource_t" use="optional" />
    <xs:attribute name="AcctTyp" type="AllocAccountType_t" use="optional" />
    <xs:attribute name="AvgPx" type="AvgPx_t" use="required" />
    <xs:attribute name="AvgPxPrcsn" type="AvgPxPrecision_t" use="optional" />
    <xs:attribute name="PxTyp" type="PriceType_t" use="optional" />
    <xs:attribute name="AvgParPx" type="AvgParPx_t" use="optional" />
    <xs:attribute name="RptedPx" type="ReportedPx_t" use="optional" />
    <xs:attribute name="Txt" type="Text_t" use="optional" />
    <xs:attribute name="EncTxtLen" type="EncodedTextLen_t" use="optional" />
    <xs:attribute name="EncTxt" type="EncodedText_t" use="optional" />
    <xs:attribute name="ProcCode" type="ProcessCode_t" use="optional" />
    <xs:attribute name="GrossTrdAmt" type="GrossTradeAmt_t" use="required" />
    <xs:attribute name="NumDaysInt" type="NumDaysInterest_t" use="optional" />
    <xs:attribute name="ExDt" type="ExDate_t" use="optional" />
    <xs:attribute name="AcrdIntRt" type="AccruedInterestRate_t" use="optional" />
    <xs:attribute name="AcrdIntAmt" type="AccruedInterestAmt_t" use="optional" />
    <xs:attribute name="IntAtMat" type="InterestAtMaturity_t" use="optional" />
    <xs:attribute name="EndAcrdIntAmt" type="EndAccruedInterestAmt_t" use="optional" />
    <xs:attribute name="StartCsh" type="StartCash_t" use="optional" />
    <xs:attribute name="EndCsh" type="EndCash_t" use="optional" />
    <xs:attribute name="Concession" type="Concession_t" use="optional" />
    <xs:attribute name="TotTakedown" type="TotalTakedown_t" use="optional" />
    <xs:attribute name="NetMny" type="NetMoney_t" use="required" />
    <xs:attribute name="MatNetMny" type="MaturityNetMoney_t" use="optional" />
    <xs:attribute name="SettlCurrAmt" type="SettlCurrAmt_t" use="optional" />
    <xs:attribute name="SettlCcy" type="SettlCurrency_t" use="optional" />
    <xs:attribute name="SettlCurrFxRt" type="SettlCurrFxRate_t" use="optional" />
    <xs:attribute name="SettlCurrFxRtCalc" type="SettlCurrFxRateCalc_t" use="optional" />
    <xs:attribute name="SettlTyp" type="SettlType_t" use="optional" />
    <xs:attribute name="SettlDt" type="SettlDate_t" use="optional" />
    <xs:attribute name="SharedComm" type="SharedCommission_t" use="optional" />
</xs:attributeGroup>
Collapse Child Attributes:
Name Type Default Value Use
CnfmID nsA:CnfmID Required
CnfmRefID nsA:CnfmRefID Optional
CnfmReqID nsA:CnfmReqID Optional
CnfmTransTyp nsA:CnfmTransTyp Required
CnfmTyp nsA:CnfmTyp Required
CopyMsgInd nsA:CopyMsgInd Optional
LegalCnfm nsA:LegalCnfm Optional
CnfmStat nsA:CnfmStat Required
AllocID nsA:AllocID Optional
AllocID2 nsA:AllocID2 Optional
IndAllocID nsA:IndAllocID Optional
TxnTm nsA:TxnTm Required
TrdDt nsA:TrdDt Required
Qty nsA:Qty Required
QtyTyp nsA:QtyTyp Optional
Side nsA:Side Required
Ccy nsA:Ccy Optional
LastMkt nsA:LastMkt Optional
Acct nsA:Acct Required
ActIDSrc nsA:ActIDSrc Optional
AcctTyp nsA:AcctTyp Optional
AvgPx nsA:AvgPx Required
AvgPxPrcsn nsA:AvgPxPrcsn Optional
PxTyp nsA:PxTyp Optional
AvgParPx nsA:AvgParPx Optional
RptedPx nsA:RptedPx Optional
Txt nsA:Txt Optional
EncTxtLen nsA:EncTxtLen Optional
EncTxt nsA:EncTxt Optional
ProcCode nsA:ProcCode Optional
GrossTrdAmt nsA:GrossTrdAmt Required
NumDaysInt nsA:NumDaysInt Optional
ExDt nsA:ExDt Optional
AcrdIntRt nsA:AcrdIntRt Optional
AcrdIntAmt nsA:AcrdIntAmt Optional
IntAtMat nsA:IntAtMat Optional
EndAcrdIntAmt nsA:EndAcrdIntAmt Optional
StartCsh nsA:StartCsh Optional
EndCsh nsA:EndCsh Optional
Concession nsA:Concession Optional
TotTakedown nsA:TotTakedown Optional
NetMny nsA:NetMny Required
MatNetMny nsA:MatNetMny Optional
SettlCurrAmt nsA:SettlCurrAmt Optional
SettlCcy nsA:SettlCcy Optional
SettlCurrFxRt nsA:SettlCurrFxRt Optional
SettlCurrFxRtCalc nsA:SettlCurrFxRtCalc Optional
SettlTyp nsA:SettlTyp Optional
SettlDt nsA:SettlDt Optional
SharedComm nsA:SharedComm Optional
