Documentation for Financial Information eXchange (FIX)
Definition Type: AttributeGroup
Name: OrderStatusRequestAttributes
Namespace: http://www.fixprotocol.org/FIXML-4-4
Containing Schema: fixml-order-base-4-4.xsd
Collapse XSD Schema Diagram:
Drilldown into Side in schema fixml-order-base-4-4_xsd Drilldown into AcctIDSrc in schema fixml-order-base-4-4_xsd Drilldown into Acct in schema fixml-order-base-4-4_xsd Drilldown into StatReqID in schema fixml-order-base-4-4_xsd Drilldown into LnkID in schema fixml-order-base-4-4_xsd Drilldown into ID2 in schema fixml-order-base-4-4_xsd Drilldown into ID in schema fixml-order-base-4-4_xsd Drilldown into OrdID in schema fixml-order-base-4-4_xsdXSD Diagram of OrderStatusRequestAttributes in schema fixml-order-base-4-4_xsd (Financial Information eXchange (FIX))
Collapse XSD Schema Code:
<xs:attributeGroup name="OrderStatusRequestAttributes">
    <xs:attribute name="OrdID" type="OrderID_t" use="optional" />
    <xs:attribute name="ID" type="ClOrdID_t" use="required" />
    <xs:attribute name="ID2" type="SecondaryClOrdID_t" use="optional" />
    <xs:attribute name="LnkID" type="ClOrdLinkID_t" use="optional" />
    <xs:attribute name="StatReqID" type="OrdStatusReqID_t" use="optional" />
    <xs:attribute name="Acct" type="Account_t" use="optional" />
    <xs:attribute name="AcctIDSrc" type="AcctIDSource_t" use="optional" />
    <xs:attribute name="Side" type="Side_t" use="required" />
</xs:attributeGroup>
Collapse Child Attributes:
Name Type Default Value Use
OrdID nsA:OrdID Optional
ID nsA:ID Required
ID2 nsA:ID2 Optional
LnkID nsA:LnkID Optional
StatReqID nsA:StatReqID Optional
Acct nsA:Acct Optional
AcctIDSrc nsA:AcctIDSrc Optional
Side nsA:Side Required
