Documentation for Financial Information eXchange (FIX)
Definition Type: AttributeGroup
Name: TradeCaptureReportAckAttributes
Namespace: http://www.fixprotocol.org/FIXML-4-4
Containing Schema: fixml-tradecapture-base-4-4.xsd
Collapse XSD Schema Diagram:
Drilldown into PreallocMeth in schema fixml-tradecapture-base-4-4_xsd Drilldown into PosEfct in schema fixml-tradecapture-base-4-4_xsd Drilldown into AcctTyp in schema fixml-tradecapture-base-4-4_xsd Drilldown into AcctIDSrc in schema fixml-tradecapture-base-4-4_xsd Drilldown into Acct in schema fixml-tradecapture-base-4-4_xsd Drilldown into CustCpcty in schema fixml-tradecapture-base-4-4_xsd Drilldown into Rstctions in schema fixml-tradecapture-base-4-4_xsd Drilldown into Cpcty in schema fixml-tradecapture-base-4-4_xsd Drilldown into ClrFeeInd in schema fixml-tradecapture-base-4-4_xsd Drilldown into EncTxt in schema fixml-tradecapture-base-4-4_xsd Drilldown into EncTxtLen in schema fixml-tradecapture-base-4-4_xsd Drilldown into Txt in schema fixml-tradecapture-base-4-4_xsd Drilldown into RspDest in schema fixml-tradecapture-base-4-4_xsd Drilldown into RspTransportTyp in schema fixml-tradecapture-base-4-4_xsd Drilldown into TxnTm in schema fixml-tradecapture-base-4-4_xsd Drilldown into ExecID2 in schema fixml-tradecapture-base-4-4_xsd Drilldown into ExecID in schema fixml-tradecapture-base-4-4_xsd Drilldown into TrdMtchID in schema fixml-tradecapture-base-4-4_xsd Drilldown into LinkID in schema fixml-tradecapture-base-4-4_xsd Drilldown into SubReqTyp in schema fixml-tradecapture-base-4-4_xsd Drilldown into RptID2 in schema fixml-tradecapture-base-4-4_xsd Drilldown into RptRejRsn in schema fixml-tradecapture-base-4-4_xsd Drilldown into TrdRptStat in schema fixml-tradecapture-base-4-4_xsd Drilldown into RptRefID2 in schema fixml-tradecapture-base-4-4_xsd Drilldown into RptRefID in schema fixml-tradecapture-base-4-4_xsd Drilldown into ExecTyp in schema fixml-tradecapture-base-4-4_xsd Drilldown into TrnsfrRsn in schema fixml-tradecapture-base-4-4_xsd Drilldown into TrdTyp2 in schema fixml-tradecapture-base-4-4_xsd Drilldown into TrdSubTyp in schema fixml-tradecapture-base-4-4_xsd Drilldown into TrdTyp in schema fixml-tradecapture-base-4-4_xsd Drilldown into RptTyp in schema fixml-tradecapture-base-4-4_xsd Drilldown into TransTyp in schema fixml-tradecapture-base-4-4_xsd Drilldown into RptID in schema fixml-tradecapture-base-4-4_xsdXSD Diagram of TradeCaptureReportAckAttributes in schema fixml-tradecapture-base-4-4_xsd (Financial Information eXchange (FIX))
Collapse XSD Schema Code:
<xs:attributeGroup name="TradeCaptureReportAckAttributes">
    <xs:attribute name="RptID" type="TradeReportID_t" use="required" />
    <xs:attribute name="TransTyp" type="TradeReportTransType_t" use="optional" />
    <xs:attribute name="RptTyp" type="TradeReportType_t" use="optional" />
    <xs:attribute name="TrdTyp" type="TrdType_t" use="optional" />
    <xs:attribute name="TrdSubTyp" type="TrdSubType_t" use="optional" />
    <xs:attribute name="TrdTyp2" type="SecondaryTrdType_t" use="optional" />
    <xs:attribute name="TrnsfrRsn" type="TransferReason_t" use="optional" />
    <xs:attribute name="ExecTyp" type="ExecType_t" use="required" />
    <xs:attribute name="RptRefID" type="TradeReportRefID_t" use="optional" />
    <xs:attribute name="RptRefID2" type="SecondaryTradeReportRefID_t" use="optional" />
    <xs:attribute name="TrdRptStat" type="TrdRptStatus_t" use="optional" />
    <xs:attribute name="RptRejRsn" type="TradeReportRejectReason_t" use="optional" />
    <xs:attribute name="RptID2" type="SecondaryTradeReportID_t" use="optional" />
    <xs:attribute name="SubReqTyp" type="SubscriptionRequestType_t" use="optional" />
    <xs:attribute name="LinkID" type="TradeLinkID_t" use="optional" />
    <xs:attribute name="TrdMtchID" type="TrdMatchID_t" use="optional" />
    <xs:attribute name="ExecID" type="ExecID_t" use="optional" />
    <xs:attribute name="ExecID2" type="SecondaryExecID_t" use="optional" />
    <xs:attribute name="TxnTm" type="TransactTime_t" use="optional" />
    <xs:attribute name="RspTransportTyp" type="ResponseTransportType_t" use="optional" />
    <xs:attribute name="RspDest" type="ResponseDestination_t" use="optional" />
    <xs:attribute name="Txt" type="Text_t" use="optional" />
    <xs:attribute name="EncTxtLen" type="EncodedTextLen_t" use="optional" />
    <xs:attribute name="EncTxt" type="EncodedText_t" use="optional" />
    <xs:attribute name="ClrFeeInd" type="ClearingFeeIndicator_t" use="optional" />
    <xs:attribute name="Cpcty" type="OrderCapacity_t" use="optional" />
    <xs:attribute name="Rstctions" type="OrderRestrictions_t" use="optional" />
    <xs:attribute name="CustCpcty" type="CustOrderCapacity_t" use="optional" />
    <xs:attribute name="Acct" type="Account_t" use="optional" />
    <xs:attribute name="AcctIDSrc" type="AcctIDSource_t" use="optional" />
    <xs:attribute name="AcctTyp" type="AccountType_t" use="optional" />
    <xs:attribute name="PosEfct" type="PositionEffect_t" use="optional" />
    <xs:attribute name="PreallocMeth" type="PreallocMethod_t" use="optional" />
</xs:attributeGroup>
Collapse Child Attributes:
Name Type Default Value Use
RptID nsA:RptID Required
TransTyp nsA:TransTyp Optional
RptTyp nsA:RptTyp Optional
TrdTyp nsA:TrdTyp Optional
TrdSubTyp nsA:TrdSubTyp Optional
TrdTyp2 nsA:TrdTyp2 Optional
TrnsfrRsn nsA:TrnsfrRsn Optional
ExecTyp nsA:ExecTyp Required
RptRefID nsA:RptRefID Optional
RptRefID2 nsA:RptRefID2 Optional
TrdRptStat nsA:TrdRptStat Optional
RptRejRsn nsA:RptRejRsn Optional
RptID2 nsA:RptID2 Optional
SubReqTyp nsA:SubReqTyp Optional
LinkID nsA:LinkID Optional
TrdMtchID nsA:TrdMtchID Optional
ExecID nsA:ExecID Optional
ExecID2 nsA:ExecID2 Optional
TxnTm nsA:TxnTm Optional
RspTransportTyp nsA:RspTransportTyp Optional
RspDest nsA:RspDest Optional
Txt nsA:Txt Optional
EncTxtLen nsA:EncTxtLen Optional
EncTxt nsA:EncTxt Optional
ClrFeeInd nsA:ClrFeeInd Optional
Cpcty nsA:Cpcty Optional
Rstctions nsA:Rstctions Optional
CustCpcty nsA:CustCpcty Optional
Acct nsA:Acct Optional
AcctIDSrc nsA:AcctIDSrc Optional
AcctTyp nsA:AcctTyp Optional
PosEfct nsA:PosEfct Optional
PreallocMeth nsA:PreallocMeth Optional
