Documentation for Financial Information eXchange (FIX)
Definition Type: AttributeGroup
Name: TradingSessionStatusAttributes
Namespace: http://www.fixprotocol.org/FIXML-4-4
Containing Schema: fixml-securitystatus-base-4-4.xsd
Collapse XSD Schema Diagram:
Drilldown into EncTxt in schema fixml-securitystatus-base-4-4_xsd Drilldown into EncTxtLen in schema fixml-securitystatus-base-4-4_xsd Drilldown into Txt in schema fixml-securitystatus-base-4-4_xsd Drilldown into TotVolTrdd in schema fixml-securitystatus-base-4-4_xsd Drilldown into EndTm in schema fixml-securitystatus-base-4-4_xsd Drilldown into ClsTm in schema fixml-securitystatus-base-4-4_xsd Drilldown into PreClsTm in schema fixml-securitystatus-base-4-4_xsd Drilldown into OpenTm in schema fixml-securitystatus-base-4-4_xsd Drilldown into StartTm in schema fixml-securitystatus-base-4-4_xsd Drilldown into StatRejRsn in schema fixml-securitystatus-base-4-4_xsd Drilldown into Stat in schema fixml-securitystatus-base-4-4_xsd Drilldown into Unsol in schema fixml-securitystatus-base-4-4_xsd Drilldown into Mode in schema fixml-securitystatus-base-4-4_xsd Drilldown into Method in schema fixml-securitystatus-base-4-4_xsd Drilldown into SesSub in schema fixml-securitystatus-base-4-4_xsd Drilldown into SesID in schema fixml-securitystatus-base-4-4_xsd Drilldown into ReqID in schema fixml-securitystatus-base-4-4_xsdXSD Diagram of TradingSessionStatusAttributes in schema fixml-securitystatus-base-4-4_xsd (Financial Information eXchange (FIX))
Collapse XSD Schema Code:
<xs:attributeGroup name="TradingSessionStatusAttributes">
    <xs:attribute name="ReqID" type="TradSesReqID_t" use="optional" />
    <xs:attribute name="SesID" type="TradingSessionID_t" use="required" />
    <xs:attribute name="SesSub" type="TradingSessionSubID_t" use="optional" />
    <xs:attribute name="Method" type="TradSesMethod_t" use="optional" />
    <xs:attribute name="Mode" type="TradSesMode_t" use="optional" />
    <xs:attribute name="Unsol" type="UnsolicitedIndicator_t" use="optional" />
    <xs:attribute name="Stat" type="TradSesStatus_t" use="required" />
    <xs:attribute name="StatRejRsn" type="TradSesStatusRejReason_t" use="optional" />
    <xs:attribute name="StartTm" type="TradSesStartTime_t" use="optional" />
    <xs:attribute name="OpenTm" type="TradSesOpenTime_t" use="optional" />
    <xs:attribute name="PreClsTm" type="TradSesPreCloseTime_t" use="optional" />
    <xs:attribute name="ClsTm" type="TradSesCloseTime_t" use="optional" />
    <xs:attribute name="EndTm" type="TradSesEndTime_t" use="optional" />
    <xs:attribute name="TotVolTrdd" type="TotalVolumeTraded_t" use="optional" />
    <xs:attribute name="Txt" type="Text_t" use="optional" />
    <xs:attribute name="EncTxtLen" type="EncodedTextLen_t" use="optional" />
    <xs:attribute name="EncTxt" type="EncodedText_t" use="optional" />
</xs:attributeGroup>
Collapse Child Attributes:
Name Type Default Value Use
ReqID nsA:ReqID Optional
SesID nsA:SesID Required
SesSub nsA:SesSub Optional
Method nsA:Method Optional
Mode nsA:Mode Optional
Unsol nsA:Unsol Optional
Stat nsA:Stat Required
StatRejRsn nsA:StatRejRsn Optional
StartTm nsA:StartTm Optional
OpenTm nsA:OpenTm Optional
PreClsTm nsA:PreClsTm Optional
ClsTm nsA:ClsTm Optional
EndTm nsA:EndTm Optional
TotVolTrdd nsA:TotVolTrdd Optional
Txt nsA:Txt Optional
EncTxtLen nsA:EncTxtLen Optional
EncTxt nsA:EncTxt Optional
