Documentation for Office Open XML (OOXML / OpenXML / Ecma 376)
Definition Type: ComplexType
Name: CT_ClientData
Namespace: urn:schemas-microsoft-com:office:excel
Containing Schema: vml-spreadsheetDrawing.xsd
Abstract
Collapse XSD Schema Diagram:
Drilldown into FmlaTxbx in schema vml-spreadsheetdrawing_xsd Drilldown into ScriptLocation in schema vml-spreadsheetdrawing_xsd Drilldown into ScriptLanguage in schema vml-spreadsheetdrawing_xsd Drilldown into ScriptExtended in schema vml-spreadsheetdrawing_xsd Drilldown into ScriptText in schema vml-spreadsheetdrawing_xsd Drilldown into UIObj in schema vml-spreadsheetdrawing_xsd Drilldown into DDE in schema vml-spreadsheetdrawing_xsd Drilldown into AutoScale in schema vml-spreadsheetdrawing_xsd Drilldown into RecalcAlways in schema vml-spreadsheetdrawing_xsd Drilldown into Camera in schema vml-spreadsheetdrawing_xsd Drilldown into CF in schema vml-spreadsheetdrawing_xsd Drilldown into MapOCX in schema vml-spreadsheetdrawing_xsd Drilldown into Dx in schema vml-spreadsheetdrawing_xsd Drilldown into Horiz in schema vml-spreadsheetdrawing_xsd Drilldown into Page in schema vml-spreadsheetdrawing_xsd Drilldown into Inc in schema vml-spreadsheetdrawing_xsd Drilldown into Max in schema vml-spreadsheetdrawing_xsd Drilldown into Min in schema vml-spreadsheetdrawing_xsd Drilldown into Val in schema vml-spreadsheetdrawing_xsd Drilldown into FmlaGroup in schema vml-spreadsheetdrawing_xsd Drilldown into FirstButton in schema vml-spreadsheetdrawing_xsd Drilldown into NoThreeD in schema vml-spreadsheetdrawing_xsd Drilldown into FmlaPict in schema vml-spreadsheetdrawing_xsd Drilldown into FmlaLink in schema vml-spreadsheetdrawing_xsd Drilldown into Checked in schema vml-spreadsheetdrawing_xsd Drilldown into DropLines in schema vml-spreadsheetdrawing_xsd Drilldown into Colored in schema vml-spreadsheetdrawing_xsd Drilldown into DropStyle in schema vml-spreadsheetdrawing_xsd Drilldown into ListItem in schema vml-spreadsheetdrawing_xsd Drilldown into LCT in schema vml-spreadsheetdrawing_xsd Drilldown into MultiSel in schema vml-spreadsheetdrawing_xsd Drilldown into SelType in schema vml-spreadsheetdrawing_xsd Drilldown into NoThreeD2 in schema vml-spreadsheetdrawing_xsd Drilldown into Sel in schema vml-spreadsheetdrawing_xsd Drilldown into WidthMin in schema vml-spreadsheetdrawing_xsd Drilldown into FmlaRange in schema vml-spreadsheetdrawing_xsd Drilldown into ValidIds in schema vml-spreadsheetdrawing_xsd Drilldown into VScroll in schema vml-spreadsheetdrawing_xsd Drilldown into MultiLine in schema vml-spreadsheetdrawing_xsd Drilldown into VTEdit in schema vml-spreadsheetdrawing_xsd Drilldown into ColHidden in schema vml-spreadsheetdrawing_xsd Drilldown into RowHidden in schema vml-spreadsheetdrawing_xsd Drilldown into Visible in schema vml-spreadsheetdrawing_xsd Drilldown into Column in schema vml-spreadsheetdrawing_xsd Drilldown into Row in schema vml-spreadsheetdrawing_xsd Drilldown into Accel2 in schema vml-spreadsheetdrawing_xsd Drilldown into Accel in schema vml-spreadsheetdrawing_xsd Drilldown into Dismiss in schema vml-spreadsheetdrawing_xsd Drilldown into Cancel in schema vml-spreadsheetdrawing_xsd Drilldown into Help in schema vml-spreadsheetdrawing_xsd Drilldown into Default in schema vml-spreadsheetdrawing_xsd Drilldown into SecretEdit in schema vml-spreadsheetdrawing_xsd Drilldown into JustLastX in schema vml-spreadsheetdrawing_xsd Drilldown into LockText in schema vml-spreadsheetdrawing_xsd Drilldown into TextVAlign in schema vml-spreadsheetdrawing_xsd Drilldown into TextHAlign in schema vml-spreadsheetdrawing_xsd Drilldown into FmlaMacro in schema vml-spreadsheetdrawing_xsd Drilldown into AutoPict in schema vml-spreadsheetdrawing_xsd Drilldown into AutoLine in schema vml-spreadsheetdrawing_xsd Drilldown into AutoFill in schema vml-spreadsheetdrawing_xsd Drilldown into Disabled in schema vml-spreadsheetdrawing_xsd Drilldown into PrintObject in schema vml-spreadsheetdrawing_xsd Drilldown into DefaultSize in schema vml-spreadsheetdrawing_xsd Drilldown into Locked in schema vml-spreadsheetdrawing_xsd Drilldown into Anchor in schema vml-spreadsheetdrawing_xsd Drilldown into SizeWithCells in schema vml-spreadsheetdrawing_xsd Drilldown into MoveWithCells in schema vml-spreadsheetdrawing_xsd Drilldown into ObjectType in schema vml-spreadsheetdrawing_xsdXSD Diagram of CT_ClientData in schema vml-spreadsheetdrawing_xsd (Office Open XML (OOXML / OpenXML / Ecma 376))
Collapse XSD Schema Code:
<xsd:complexType name="CT_ClientData">
    <xsd:choice minOccurs="0" maxOccurs="unbounded">
        <xsd:element name="MoveWithCells" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Move with Cells</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="SizeWithCells" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Resize with Cells</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Anchor" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>Anchor</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Locked" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Lock Toggle</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="DefaultSize" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Default Size Toggle</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="PrintObject" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Print Toggle</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Disabled" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Macro Disable Toggle</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="AutoFill" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>AutoFill</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="AutoLine" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>AutoLine</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="AutoPict" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Automatically Size</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="FmlaMacro" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>Reference to Custom Function</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="TextHAlign" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>Horizontal Text Alignment</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="TextVAlign" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>Vertical Text Alignment</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="LockText" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Text Lock</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="JustLastX" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Far East Alignment Toggle</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="SecretEdit" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Password Edit</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Default" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Default Button</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Help" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Help Button</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Cancel" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Cancel Button</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Dismiss" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Dismiss Button</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Accel" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Primary Keyboard Accelerator</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Accel2" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Secondary Keyboard Accelerator</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Row" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Comment Row Target</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Column" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Comment Column Target</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Visible" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Comment Visibility Toggle</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="RowHidden" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Comment's Row is Hidden</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="ColHidden" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Comment's Column is Hidden</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="VTEdit" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Validation Type</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="MultiLine" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Multi-line</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="VScroll" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Vertical Scroll</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="ValidIds" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Valid ID</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="FmlaRange" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>List Items Source Range</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="WidthMin" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Minimum Width</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Sel" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Selected Entry</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="NoThreeD2" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Disable 3D</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="SelType" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>Selection Type</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="MultiSel" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>Multiple Selections</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="LCT" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>Callback Type</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="ListItem" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>Non-linked List Item</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="DropStyle" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>Dropdown Style</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Colored" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Dropdown Color Toggle</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="DropLines" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Dropdown Maximum Lines</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Checked" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Checked</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="FmlaLink" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>Linked Formula</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="FmlaPict" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>Camera Source Range</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="NoThreeD" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Disable 3D</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="FirstButton" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>First Radio Button</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="FmlaGroup" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>Linked Formula - Group Box</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Val" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Scroll bar position</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Min" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Scroll Bar Minimum</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Max" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Scroll Bar Maximum</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Inc" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Scroll Bar Increment</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Page" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Scroll Bar Page Increment</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Horiz" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Scroll Bar Orientation</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Dx" type="xsd:integer">
            <xsd:annotation>
                <xsd:documentation>Scroll Bar Width</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="MapOCX" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>ActiveX Control</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="CF" type="ST_CF">
            <xsd:annotation>
                <xsd:documentation>Clipboard Format</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="Camera" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Camera Tool</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="RecalcAlways" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Recalculation Toggle</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="AutoScale" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Font AutoScale</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="DDE" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>Dynamic Data Exchange</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="UIObj" type="ST_TrueFalseBlank">
            <xsd:annotation>
                <xsd:documentation>UI Object Toggle</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="ScriptText" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>HTML Script Text</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="ScriptExtended" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>HTML Script Attributes</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="ScriptLanguage" type="xsd:nonNegativeInteger">
            <xsd:annotation>
                <xsd:documentation>HTML Script Language</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="ScriptLocation" type="xsd:nonNegativeInteger">
            <xsd:annotation>
                <xsd:documentation>HTML Script Location</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
        <xsd:element name="FmlaTxbx" type="xsd:string">
            <xsd:annotation>
                <xsd:documentation>Text Formula</xsd:documentation>
            </xsd:annotation>
        </xsd:element>
    </xsd:choice>
    <xsd:attribute name="ObjectType" type="ST_ObjectType" use="required">
        <xsd:annotation>
            <xsd:documentation>Object type</xsd:documentation>
        </xsd:annotation>
    </xsd:attribute>
</xsd:complexType>
Collapse Child Elements:
Name Type Min Occurs Max Occurs
MoveWithCells x:MoveWithCells (1) (1)
SizeWithCells x:SizeWithCells (1) (1)
Anchor x:Anchor (1) (1)
Locked x:Locked (1) (1)
DefaultSize x:DefaultSize (1) (1)
PrintObject x:PrintObject (1) (1)
Disabled x:Disabled (1) (1)
AutoFill x:AutoFill (1) (1)
AutoLine x:AutoLine (1) (1)
AutoPict x:AutoPict (1) (1)
FmlaMacro x:FmlaMacro (1) (1)
TextHAlign x:TextHAlign (1) (1)
TextVAlign x:TextVAlign (1) (1)
LockText x:LockText (1) (1)
JustLastX x:JustLastX (1) (1)
SecretEdit x:SecretEdit (1) (1)
Default x:Default (1) (1)
Help x:Help (1) (1)
Cancel x:Cancel (1) (1)
Dismiss x:Dismiss (1) (1)
Accel x:Accel (1) (1)
Accel2 x:Accel2 (1) (1)
Row x:Row (1) (1)
Column x:Column (1) (1)
Visible x:Visible (1) (1)
RowHidden x:RowHidden (1) (1)
ColHidden x:ColHidden (1) (1)
VTEdit x:VTEdit (1) (1)
MultiLine x:MultiLine (1) (1)
VScroll x:VScroll (1) (1)
ValidIds x:ValidIds (1) (1)
FmlaRange x:FmlaRange (1) (1)
WidthMin x:WidthMin (1) (1)
Sel x:Sel (1) (1)
NoThreeD2 x:NoThreeD2 (1) (1)
SelType x:SelType (1) (1)
MultiSel x:MultiSel (1) (1)
LCT x:LCT (1) (1)
ListItem x:ListItem (1) (1)
DropStyle x:DropStyle (1) (1)
Colored x:Colored (1) (1)
DropLines x:DropLines (1) (1)
Checked x:Checked (1) (1)
FmlaLink x:FmlaLink (1) (1)
FmlaPict x:FmlaPict (1) (1)
NoThreeD x:NoThreeD (1) (1)
FirstButton x:FirstButton (1) (1)
FmlaGroup x:FmlaGroup (1) (1)
Val x:Val (1) (1)
Min x:Min (1) (1)
Max x:Max (1) (1)
Inc x:Inc (1) (1)
Page x:Page (1) (1)
Horiz x:Horiz (1) (1)
Dx x:Dx (1) (1)
MapOCX x:MapOCX (1) (1)
CF x:CF (1) (1)
Camera x:Camera (1) (1)
RecalcAlways x:RecalcAlways (1) (1)
AutoScale x:AutoScale (1) (1)
DDE x:DDE (1) (1)
UIObj x:UIObj (1) (1)
ScriptText x:ScriptText (1) (1)
ScriptExtended x:ScriptExtended (1) (1)
ScriptLanguage x:ScriptLanguage (1) (1)
ScriptLocation x:ScriptLocation (1) (1)
FmlaTxbx x:FmlaTxbx (1) (1)
Collapse Child Attributes:
Name Type Default Value Use
ObjectType x:ObjectType Required
Collapse Derivation Tree:
Collapse References:
x:ClientData
Documentation for Office Open XML (OOXML / OpenXML / Ecma 376)

Generated using Liquid Studio - Developer Bundle 21.0.0.0
