Definition Type: ComplexType
Name: TrdCapRptSideGrp_Block_t
Namespace: http://www.fixprotocol.org/FIXML-4-4
Containing Schema: fixml-tradecapture-base-4-4.xsd
Abstract
Documentation:
TrdCapRptSideGrp is a component
Collapse XSD Schema Diagram:
Drilldown into Alloc in schema fixml-tradecapture-base-4-4_xsd Drilldown into MiscFees in schema fixml-tradecapture-base-4-4_xsd Drilldown into Stip in schema fixml-tradecapture-base-4-4_xsd Drilldown into ContAmt in schema fixml-tradecapture-base-4-4_xsd Drilldown into Comm in schema fixml-tradecapture-base-4-4_xsd Drilldown into ClrInst in schema fixml-tradecapture-base-4-4_xsd Drilldown into Pty in schema fixml-tradecapture-base-4-4_xsd Drilldown into TrdCapRptSideGrpElements in schema fixml-tradecapture-base-4-4_xsd Drilldown into AllocID in schema fixml-tradecapture-base-4-4_xsd Drilldown into PreallocMeth in schema fixml-tradecapture-base-4-4_xsd Drilldown into AllocInd in schema fixml-tradecapture-base-4-4_xsd Drilldown into ExchRule in schema fixml-tradecapture-base-4-4_xsd Drilldown into MLegRptTyp in schema fixml-tradecapture-base-4-4_xsd Drilldown into EncTxt in schema fixml-tradecapture-base-4-4_xsd Drilldown into EncTxtLen in schema fixml-tradecapture-base-4-4_xsd Drilldown into Txt in schema fixml-tradecapture-base-4-4_xsd Drilldown into PosEfct in schema fixml-tradecapture-base-4-4_xsd Drilldown into SettlCurrFxRtCalc in schema fixml-tradecapture-base-4-4_xsd Drilldown into SettlCurrFxRt in schema fixml-tradecapture-base-4-4_xsd Drilldown into SettlCcy in schema fixml-tradecapture-base-4-4_xsd Drilldown into SettlCurrAmt in schema fixml-tradecapture-base-4-4_xsd Drilldown into NetMny in schema fixml-tradecapture-base-4-4_xsd Drilldown into TotTakedown in schema fixml-tradecapture-base-4-4_xsd Drilldown into Concession in schema fixml-tradecapture-base-4-4_xsd Drilldown into EndCsh in schema fixml-tradecapture-base-4-4_xsd Drilldown into StartCsh in schema fixml-tradecapture-base-4-4_xsd Drilldown into EndAcrdIntAmt in schema fixml-tradecapture-base-4-4_xsd Drilldown into IntAtMat in schema fixml-tradecapture-base-4-4_xsd Drilldown into AcrdIntAmt in schema fixml-tradecapture-base-4-4_xsd Drilldown into AcrdIntRt in schema fixml-tradecapture-base-4-4_xsd Drilldown into ExDt in schema fixml-tradecapture-base-4-4_xsd Drilldown into NumDaysInt in schema fixml-tradecapture-base-4-4_xsd Drilldown into GrossTrdAmt in schema fixml-tradecapture-base-4-4_xsd Drilldown into TmBkt in schema fixml-tradecapture-base-4-4_xsd Drilldown into SesSub in schema fixml-tradecapture-base-4-4_xsd Drilldown into SesID in schema fixml-tradecapture-base-4-4_xsd Drilldown into TransBkdTm in schema fixml-tradecapture-base-4-4_xsd Drilldown into ExecInst in schema fixml-tradecapture-base-4-4_xsd Drilldown into OrdTyp in schema fixml-tradecapture-base-4-4_xsd Drilldown into CustCpcty in schema fixml-tradecapture-base-4-4_xsd Drilldown into Rstctions in schema fixml-tradecapture-base-4-4_xsd Drilldown into Cpcty in schema fixml-tradecapture-base-4-4_xsd Drilldown into SolFlag in schema fixml-tradecapture-base-4-4_xsd Drilldown into ComplianceID in schema fixml-tradecapture-base-4-4_xsd Drilldown into Ccy in schema fixml-tradecapture-base-4-4_xsd Drilldown into OrdInptDev in schema fixml-tradecapture-base-4-4_xsd Drilldown into InptDev in schema fixml-tradecapture-base-4-4_xsd Drilldown into InptSrc in schema fixml-tradecapture-base-4-4_xsd Drilldown into ClrFeeInd in schema fixml-tradecapture-base-4-4_xsd Drilldown into OddLot in schema fixml-tradecapture-base-4-4_xsd Drilldown into ProcCode in schema fixml-tradecapture-base-4-4_xsd Drilldown into AcctTyp in schema fixml-tradecapture-base-4-4_xsd Drilldown into AcctIDSrc in schema fixml-tradecapture-base-4-4_xsd Drilldown into Acct in schema fixml-tradecapture-base-4-4_xsd Drilldown into ListID in schema fixml-tradecapture-base-4-4_xsd Drilldown into ClOrdID2 in schema fixml-tradecapture-base-4-4_xsd Drilldown into ClOrdID in schema fixml-tradecapture-base-4-4_xsd Drilldown into OrdID2 in schema fixml-tradecapture-base-4-4_xsd Drilldown into OrdID in schema fixml-tradecapture-base-4-4_xsd Drilldown into Side in schema fixml-tradecapture-base-4-4_xsd Drilldown into TrdCapRptSideGrpAttributes in schema fixml-tradecapture-base-4-4_xsdXSD Diagram of TrdCapRptSideGrp_Block_t in schema fixml-tradecapture-base-4-4_xsd (Financial Information eXchange (FIX))
Collapse XSD Schema Code:
<xs:complexType name="TrdCapRptSideGrp_Block_t" final="#all">
    <xs:annotation>
        <xs:documentation xml:lang="en">TrdCapRptSideGrp is a component
		</xs:documentation>
        <xs:appinfo xmlns:x="http://www.fixprotocol.org/fixml/metadata.xsd">
            <xs:Xref Protocol="FIX" name="TrdCapRptSideGrp" ComponentType="ImplicitBlockRepeating" />
            <xs:Xref Protocol="ISO_15022_XML" />
        </xs:appinfo>
    </xs:annotation>
    <xs:sequence>
        <xs:group ref="TrdCapRptSideGrpElements" />
    </xs:sequence>
    <xs:attributeGroup ref="TrdCapRptSideGrpAttributes" />
</xs:complexType>
Collapse Child Elements:
Name Type Min Occurs Max Occurs
Pty nsA:Pty 0 unbounded
ClrInst nsA:ClrInst 0 unbounded
Comm nsA:Comm 0 (1)
ContAmt nsA:ContAmt 0 unbounded
Stip nsA:Stip 0 unbounded
MiscFees nsA:MiscFees 0 unbounded
Alloc nsA:Alloc 0 unbounded
<xs:group> nsA:TrdCapRptSideGrpElements (1) (1)
Collapse Child Attributes:
Name Type Default Value Use
Side nsA:Side Required
OrdID nsA:OrdID Required
OrdID2 nsA:OrdID2 Optional
ClOrdID nsA:ClOrdID Optional
ClOrdID2 nsA:ClOrdID2 Optional
ListID nsA:ListID Optional
Acct nsA:Acct Optional
AcctIDSrc nsA:AcctIDSrc Optional
AcctTyp nsA:AcctTyp Optional
ProcCode nsA:ProcCode Optional
OddLot nsA:OddLot Optional
ClrFeeInd nsA:ClrFeeInd Optional
InptSrc nsA:InptSrc Optional
InptDev nsA:InptDev Optional
OrdInptDev nsA:OrdInptDev Optional
Ccy nsA:Ccy Optional
ComplianceID nsA:ComplianceID Optional
SolFlag nsA:SolFlag Optional
Cpcty nsA:Cpcty Optional
Rstctions nsA:Rstctions Optional
CustCpcty nsA:CustCpcty Optional
OrdTyp nsA:OrdTyp Optional
ExecInst nsA:ExecInst Optional
TransBkdTm nsA:TransBkdTm Optional
SesID nsA:SesID Optional
SesSub nsA:SesSub Optional
TmBkt nsA:TmBkt Optional
GrossTrdAmt nsA:GrossTrdAmt Optional
NumDaysInt nsA:NumDaysInt Optional
ExDt nsA:ExDt Optional
AcrdIntRt nsA:AcrdIntRt Optional
AcrdIntAmt nsA:AcrdIntAmt Optional
IntAtMat nsA:IntAtMat Optional
EndAcrdIntAmt nsA:EndAcrdIntAmt Optional
StartCsh nsA:StartCsh Optional
EndCsh nsA:EndCsh Optional
Concession nsA:Concession Optional
TotTakedown nsA:TotTakedown Optional
NetMny nsA:NetMny Optional
SettlCurrAmt nsA:SettlCurrAmt Optional
SettlCcy nsA:SettlCcy Optional
SettlCurrFxRt nsA:SettlCurrFxRt Optional
SettlCurrFxRtCalc nsA:SettlCurrFxRtCalc Optional
PosEfct nsA:PosEfct Optional
Txt nsA:Txt Optional
EncTxtLen nsA:EncTxtLen Optional
EncTxt nsA:EncTxt Optional
MLegRptTyp nsA:MLegRptTyp Optional
ExchRule nsA:ExchRule Optional
AllocInd nsA:AllocInd Optional
PreallocMeth nsA:PreallocMeth Optional
AllocID nsA:AllocID Optional
Collapse Derivation Tree:
Collapse References:
nsA:RptSide
